Spicer90-4-571-1X SPL90 End Yoke

Description

Spicer 90-4-571-1X SPL90 End Yoke
9045711X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

90-4-571-1X
JOINT SERIES:SPL90
D DIMENSION:1.625
E DIMENSION:4.957
YOKE STYLE:Bearing Strap
Q LENGTH THRU HOLE:2.125
R HUB DIAMETER:3
S CENTERLINE TO END:4.25
SPLINE COUNT:38 I
SPLINE OD:1.998
NOTES:

Cross References:
Daimler: SP 90 4 571 1X, Daimler: SP 90 4 571 1XHP, Dana Commercial Vehicle Service Parts: 2104-9045711X, Dana Commercial Vehicle Service Parts: 4.9-4-571-1X, Freightliner Trucks: SP 90 4 571 1X, Freightliner Trucks: SP 90 4 571 1XHP, International Harvester (IHC): 1689514C91, International Harvester (IHC): 9045711X, International Harvester (IHC): D9045711X, International Harvester (IHC): E9045711X, Mack: 2104-9045711X, Navistar: 1689514C91, Navistar: 9045711X, Navistar: D9045711X, Navistar: DS9045711X, Navistar: E9045711X, UAP: 90-4-571-1X, Volvo Cars: 2104-9045711X, Volvo Cars: SP 9045711X, P90-4-571-1X

UPC:

00023913247799

Series:

SPL90

Material:

Steel

Prop 65:

No

Type:

Splined Hole

Spline Count:

38

Involute Spline:

Y

Hub Diameter R:

3.000

Length Thru Hole Q:

2.125

Yoke Style:

BS

C/L To End Hub S:

4.250

Assembly:

Y

Includes Slinger/Plug:

Y

Yoke Bearing Dimension (In) D:

1.625

Major Diameter:

1.998

Outside Yoke Dimension (In) E:

5.375
