Spicer5-4-6441-1X End Yoke 2.024″ X 39Spl

Description

Spicer 5-4-6441-1X End Yoke 2.024″X39Spl
5464411X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

5-4-6441-1X
JOINT SERIES:1610
D DIMENSION:1.875
E DIMENSION:5.312
YOKE STYLE:Half Round
Q LENGTH THRU HOLE:2.312
R HUB DIAMETER:3
S CENTERLINE TO END:4.875
SPLINE COUNT:39
SPLINE OD:2.024
NOTES:

Cross References:
Daimler: 680 410 23 08, Daimler: SP 5 4 6441 1X, Daimler: SP 5 4 6441 1XHP, Dana Commercial Vehicle Service Parts: 2104-5464411X, Freightliner Trucks: 5-4-6441-1X, Freightliner Trucks: 680 410 23 08, Freightliner Trucks: SP 5 4 6441 1X, Freightliner Trucks: SP 5 4 6441 1XHP, International Harvester (IHC): 1620099C1, International Harvester (IHC): 1620099C91, International Harvester (IHC): 5464411X, International Harvester (IHC): D5464411X, International Harvester (IHC): E5464411X, Mack: 2104-5464411X, Meritor: 16TYS3260A, Meritor: 16TYS3286A, Navistar: 1620099C1, Navistar: 1620099C91, Navistar: 5464411X, Navistar: D5464411X, Navistar: DS5464411X, Navistar: E5464411X, Neapco: N5-4-6441-1X, Paccar Parts: 5-4-6441-1X, Rockwell International: 16TYS3260A, UAP: 5-4-6441-1X, Volvo Cars: 2104-5464411X, Volvo Cars: 8160521, Volvo Cars: SP 5464411X, 5464211, P5-4-6441-1X, 16TYS32-86A

UPC:

00023913216863

Series:

1610

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Type:

Splined Hole

Spline Count:

39

Involute Spline:

N

Hub Diameter R:

3.000

Length Thru Hole Q:

2.312

Yoke Style:

HR

C/L To End Hub S:

4.875

C-Bore Depth:

0.090

Assembly:

Y

Includes Slinger/Plug:

Y

Major Diameter:

2.024
