Spicer250-4-101-1X SPL250 End Yoke

Description

Spicer 250-4-101-1X SPL250 End Yoke
25041011X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

250-4-101-1X
JOINT SERIES:SPL250
D DIMENSION:2.362
E DIMENSION:6.412
YOKE STYLE:Half Round
Q LENGTH THRU HOLE:3.195
R HUB DIAMETER:3.375
S CENTERLINE TO END:6.76
SPLINE COUNT:46 I
SPLINE OD:2.39
NOTES:

Cross References:
Daimler: 30071-3420, Daimler: SP 250 4 101 1X, Daimler: SP 250 4 101 1XHP, Daimler: SP 250-4-101-1X, Dana Commercial Vehicle Service Parts: 125MU53P21, Dana Commercial Vehicle Service Parts: 2104-2504101-1X, Dana Commercial Vehicle Service Parts: 210845, Dana Commercial Vehicle Service Parts: 250-4-91-1, Eaton: 210845, Freightliner Trucks: 30071-3420, Freightliner Trucks: SP 250 4 101 1X, Freightliner Trucks: SP 250 4 101 1XHP, Freightliner Trucks: SP 250-4-101-1X, International Harvester (IHC): 25041011X, International Harvester (IHC): 3515906C91, International Harvester (IHC): D25041011X, International Harvester (IHC): E25041011X, Mack: 125MU53P21, Mack: 2104-25041011X, Mack: 2104-2504101-1X, Mack: 25160525, McNeilus: 9HA505, Navistar: 25041011X, Navistar: 3515906C91, Navistar: D25041011X, Navistar: DS25041011X, Navistar: E25041011X, Navistar: ETN0210845, Paccar Parts: 250-4-101-1X, Peterbilt: 9HA505, UAP: 250-4-101-1X, Volvo Cars: 125MU53P21, Volvo Cars: 2104-2504101-1X, Volvo Cars: 8081945, Volvo Cars: SP 25041011X, P250-4-101-1X

UPC:

00023913248581

Series:

SPL250

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Type:

Splined Hole

Spline Count:

46

Involute Spline:

Y

Hub Diameter R:

3.375

Length Thru Hole Q:

3.195

Yoke Style:

HR

C/L To End Hub S:

6.760

C-Bore Depth:

0.580

Assembly:

Y

Includes Slinger/Plug:

Y

Yoke Bearing Dimension (In) D:

2.362

Major Diameter:

2.390

Outside Yoke Dimension (In) E:

6.417
