Spicer170-4-821-1 S400 End Yoke Spl

Description

Spicer 170-4-821-1 S400 End Yoke Spl
17048211
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

170-4-821-1
JOINT SERIES:SPL170
D DIMENSION:1.938
E DIMENSION:5.457
YOKE STYLE:Half Round
Q LENGTH THRU HOLE:2.5
R HUB DIAMETER:3
S CENTERLINE TO END:5.28
SPLINE COUNT:39 I
SPLINE OD:2.024
NOTES:

Cross References:
Daimler: SP 170 4 821 1, Daimler: SP 170 4 821 1HP, Freightliner Trucks: SP 170 4 821 1, Freightliner Trucks: SP 170 4 821 1HP, International Harvester (IHC): 17048211, International Harvester (IHC): 3515486C1, International Harvester (IHC): D17048211, International Harvester (IHC): E17048211, Navistar: 17048211, Navistar: 3515486C1, Navistar: D17048211, Navistar: DS17048211, Navistar: E17048211, Paccar Parts: 170-4-821-1, UAP: 170-4-821-1, Volvo Cars: SP 17048211, P170-4-821-1

UPC:

00023913248352

Series:

SPL170

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Type:

Splined Hole

Spline Count:

39

Involute Spline:

I

Hub Diameter R:

3.000

Length Thru Hole Q:

2.500

Yoke Style:

HR

C/L To End Hub S:

5.280

C-Bore Depth:

0.280

C-Bore Diameter:

2.09

Joint Angle 1:

25

Assembly:

N

Includes Slinger/Plug:

N

Yoke Bearing Dimension (In) D:

2.166

Major Diameter:

2.024

Outside Yoke Dimension (In) E:

6.456
