Spicer 6-82-1291 Yoke Shaft

Sale!
Spicer 6-82-1291 Yoke Shaft

Spicer 6-82-1291 Yoke Shaft

Original price was: $413.14.Current price is: $315.48.

52 in stock

SKU: DDP6-82-1291 Category:

Description

Spicer 6-82-1291 Yoke Shaft
6821291
PLEASE USE THE DANA ONILNE CENTER YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 6 82 1291HP, Elgin: 42627B30, Freightliner Trucks: SP 6 82 1291HP, Gillig Corp.: 82-20145-000, International Harvester (IHC): 1698786C1, International Harvester (IHC): 6821291, International Harvester (IHC): D6821291, International Harvester (IHC): E6821291, Navistar: 1698786C1, Navistar: 6821291, Navistar: D6821291, Navistar: DS6821291, Navistar: E6821291, New Flyer: 6313184, Paccar Parts: 6-82-1291, Terex: 9052868, UAP: 6-82-1291, Volvo Cars: SP 6821291, P6-82-1291

UPC:
00023913215736
Series:
1710
Prop 65:
No
Style:
BP
Spline Count:
16
Centerline To End Of Splne (K):
9.031
Major Spline Diameter:
2.500
Spline Length (L) In:
3.375
Spline Hole Minor Diameter:
2.125
Spline Width:
0.234
End/Spline To Point/Rad. (R):
6.281
Angle 1:
32.0
