Spicer 6.5-1-533 Rough Bore Flange

Description

Spicer 6.5-1-533 Rough Bore Flange

Cross References:
Daimler: SP 6.5 1 533HP, Dana Commercial Vehicle Service Parts: 1810-RB, Dana Commercial Vehicle Service Parts: 2104-651533, Dana Commercial Vehicle Service Parts: 6.5-1-313, Freightliner Trucks: SP 6.5 1 533HP, International Harvester (IHC): 651533, International Harvester (IHC): D651533, International Harvester (IHC): E651533, Mack: 2104-651533, McNeilus: 1408093, Navistar: 651533, Navistar: D651533, Navistar: DS651533, Navistar: E651533, Neapco: N6.5-1-533, UAP: 6.5-1-533, Volvo Cars: 2104-651533, Volvo Cars: SP 651533, P6.5-1-533, 6.51533, 65-1-533

UPC:

00023913214159

Series:

1810

Material:

Steel

Prop 65:

No

Number Of Holes:

12

Flange Type:

Circular

Pilot Diameter (C) In.:

7.750 – FEMALE

Bolt Circle Diameter (B) In.:

7.250

Actual Hole Diameter (Max):

1.250

Bore Diameter (D) In.:

1.250

Circ Flnge Face To End Of Hub:

4.000

Flange Width Diameter (A) In.:

8.00

Hub Diameter (E) In.:

6.375

Bolt Hole Diameter (In.):

.438 – DRILLED
