Spicer 6-4-8661-1X Half Round End Yoke

Description

Spicer 6-4-8661-1X Half Round End Yoke
6486611X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 6 4 8661 1X, Daimler: SP 6 4 8661 1XHP, Dana Commercial Vehicle Service Parts: 2104-6486611X, Freightliner Trucks: SP 6 4 8661 1X, Freightliner Trucks: SP 6 4 8661 1XHP, International Harvester (IHC): 1689516C91, International Harvester (IHC): 6486611X, International Harvester (IHC): D6486611X, International Harvester (IHC): E6486611X, Mack: 2104-6486611X, Navistar: 1689516C91, Navistar: 6486611X, Navistar: D6486611X, Navistar: DS6486611X, Navistar: E6486611X, Paccar Parts: 6-4-8661-1X, UAP: 6-4-8661-1X, Volvo Cars: 2104-6486611X, Volvo Cars: SP 6486611X, 6-4-8651-1, P6-4-8661-1X

UPC:

00023913218010

Series:

1710

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Type:

Splined Hole

Spline Count:

38

Involute Spline:

Y

Hub Diameter R:

3.000

Length Thru Hole Q:

2.125

Yoke Style:

HR

C/L To End Hub S:

4.844

Assembly:

Y

Includes Slinger/Plug:

Y

Yoke Bearing Dimension (In) D:

1.938

Major Diameter:

1.998

Outside Yoke Dimension (In) E:

6.190
