Spicer 6-4-8551-1X Eaton Front Input Yoke

Description

Spicer 6-4-8551-1X Eaton Front Input Yoke
6485511X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Allison Transmission: 15690224, Daimler: SP 6 4 8551 1X, Daimler: SP 6 4 8551 1XHP, Dana Commercial Vehicle Service Parts: 127752, Dana Commercial Vehicle Service Parts: 171MU51P65, Dana Commercial Vehicle Service Parts: 2104-6485511X, Dana Commercial Vehicle Service Parts: 213174, Freightliner Trucks: SP 6 4 8551 1X, Freightliner Trucks: SP 6 4 8551 1XHP, General Motors: 15690224, International Harvester (IHC): 1686787C91, International Harvester (IHC): 6485511X, International Harvester (IHC): D6485511X, Mack: 171MU51P65, Mack: 2104-6485511X, Mack: 25081027, McNeilus: 6KP902, Meritor: 17N485511X, Meritor: 17TYS36-60A, Navistar: 1686787C91, Navistar: 6485511X, Navistar: D6485511X, Navistar: DS6485511X, Navistar: ETN0127752, Navistar: ETN0213174, Navistar: ZBP0213174, Paccar Parts: 6-4-8551-1X, Peterbilt: 6KP902, Rockwell International: 17TYS36-60A, UAP: 6-4-8551-1X, Volvo Cars: 171MU51P65, Volvo Cars: 2104-6485511X, Volvo Cars: 30011-0236, Volvo Cars: SP 6485511X, 6-4-8461-1, 6-4-8551-1, 6460411X, P6-4-8551-1X

UPC:

00023913216269

Series:

1710

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Type:

Splined Hole

Spline Count:

44

Involute Spline:

Y

Hub Diameter R:

2.938

Length Thru Hole Q:

2.500

Yoke Style:

HR

C/L To End Hub S:

5.188

Assembly:

Y

Includes Slinger/Plug:

Y

Yoke Bearing Dimension (In) D:

1.938

Major Diameter:

2.274

Outside Yoke Dimension (In) E:

6.190
