Spicer 6-4-5041-1X Half Round End Yoke

Description

Spicer 6-4-5041-1X Half Round End Yoke
6450411X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Allison Transmission: 15656451, Capacity: 132468, Daimler: E7HT 7089 GA, Daimler: E7HZ 7089 G, Daimler: SP 6 4 5041 1X, Daimler: SP 6 4 5041 1XHP, Dana Commercial Vehicle Service Parts: 171MU51P33, Dana Commercial Vehicle Service Parts: 2104-6450411X, Freightliner Trucks: E7HT 7089 GA, Freightliner Trucks: E7HZ 7089 G, Freightliner Trucks: SP 6 4 5041 1X, Freightliner Trucks: SP 6 4 5041 1XHP, General Motors: 15656451, International Harvester (IHC): 1617060C91, International Harvester (IHC): 6450411X, International Harvester (IHC): D6450411X, International Harvester (IHC): E6450411X, Mack: 171MU51P33, Mack: 2104-6450411X, Navistar: 1617060C91, Navistar: 6450411X, Navistar: D6450411X, Navistar: DS6450411X, Navistar: E6450411X, Ottawa Truck: 90022389, Paccar Parts: 12-02802, Paccar Parts: 6-4-5041-1X, UAP: 6-4-5041-1X, Volvo Cars: 171MU51P33, Volvo Cars: 2104-6450411X, Volvo Cars: 30010-0018, Volvo Cars: SP 6450411X, P6-4-5041-1X, 6-4-5031-1

UPC:

00023913218928

Series:

1710

Material:

Steel

Prop 65:

No

Type:

Splined Hole

Spline Count:

34

Involute Spline:

Y

Hub Diameter R:

2.562

Length Thru Hole Q:

2.750

Yoke Style:

HR

C/L To End Hub S:

5.594

Assembly:

Y

Includes Slinger/Plug:

Y

Yoke Bearing Dimension (In) D:

1.938

Major Diameter:

1.790

Outside Yoke Dimension (In) E:

6.190
