Spicer 6-4-4601-1 Jack Shaft Yoke

Description

Spicer 6-4-4601-1 Jack Shaft Yoke
6446011
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS
NOTES:Coupling shaft yoke

Cross References:
Daimler: SP 6 4 4601 1, Daimler: SP 6 4 4601 1HP, Dana Commercial Vehicle Service Parts: 171MU51P27, Dana Commercial Vehicle Service Parts: 2104-6446011, Freightliner Trucks: SP 6 4 4601 1, Freightliner Trucks: SP 6 4 4601 1HP, International Harvester (IHC): 6 4 4601 1, International Harvester (IHC): 6446011, International Harvester (IHC): D6446011, International Harvester (IHC): E6446011, Mack: 171MU51P27, Mack: 2104-6446011, McNeilus: 2KP808, Meritor: 17N446011, Meritor: 17TYS38-8, Midwest: 6-4-4601-1R, Navistar: 6 4 4601 1, Navistar: 6446011, Navistar: D6446011, Navistar: DS6446011, Navistar: E6446011, Neapco: N6-4-4601-1, Paccar Parts: 6-4-4601-1, Peterbilt: 2KP808, Rockwell International: 17N-4-4601-1, Rockwell International: 17TYS38-8, UAP: 6-4-4601-1, Volvo Cars: 171MU51P27, Volvo Cars: 2104-6446011, Volvo Cars: SP 6446011, P6-4-4601-1

UPC:

00023913214357

Series:

1710

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Type:

Splined Hole

Spline Count:

16

Involute Spline:

N

Hub Diameter R:

3.312

Length Thru Hole Q:

2.750

Yoke Style:

HR

C/L To End Hub S:

4.938

Joint Angle 1:

20.5

Assembly:

Y

Includes Slinger/Plug:

Y

Yoke Bearing Dimension (In) D:

1.938

Major Diameter:

2.350

Outside Yoke Dimension (In) E:

6.190
