Spicer 5-82-781 Yoke Shaft 7.5 Long

Description

Spicer 5-82-781 Yoke Shaft 7.5 Long
582781
PLEASE USE THE DANA ONILNE CENTER YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Allison Transmission: 15581566, Daimler: SP 5 82 781, Daimler: SP 5 82 781HP, Dana Commercial Vehicle Service Parts: 2104-582781, Dana Commercial Vehicle Service Parts: 5-82-141, Freightliner Trucks: SP 5 82 781, Freightliner Trucks: SP 5 82 781HP, General Motors: 15581566, International Harvester (IHC): 582781, International Harvester (IHC): D582781, International Harvester (IHC): E582781, Joy: 00570339-0011, Mack: 2104-582781, Navistar: 582781, Navistar: D582781, Navistar: DS582781, Navistar: E582781, Sandvik: 009799-053, UAP: 5-82-781, Volvo Cars: 2104-582781, Volvo Cars: SP 582781, Volvo Cars: SP5-82-781, P5-82-781

UPC:

00023913214616

Series:

1610

Prop 65:

No

Style:

BP

Spline Count:

16

Centerline To End Of Splne (K):

10.812

Major Spline Diameter:

2.000

Spline Length (L) In:

3.500

Spline Hole Minor Diameter:

1.719

Spline Width:

0.188

End/Spline To Point/Rad. (R):

7.562

Angle 1:

22.0
