Spicer 5-4-5121X End Yoke 1.969″ X 10 Spline

Description

Spicer 5-4-5121X End Yoke 1.969″X10Spline
545121X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

5-4-5121X
JOINT SERIES:1610
D DIMENSION:1.875
E DIMENSION:5.312
YOKE STYLE:Bearing Plate
Q LENGTH THRU HOLE:2.25
R HUB DIAMETER:2.625
S CENTERLINE TO END:4.719
SPLINE COUNT:10
SPLINE OD:1.962
NOTES:

Cross References:
Allison Transmission: 15502990, Blue Bird: 1024397, Daimler: SP 5 4 5121X, Daimler: SP 5 4 5121XHP, Dana Commercial Vehicle Service Parts: 2104-545121X, Freightliner Trucks: SP 5 4 5121X, Freightliner Trucks: SP 5 4 5121XHP, General Motors: 15502990, International Harvester (IHC): 1676146C91, International Harvester (IHC): 545121X, International Harvester (IHC): D545121X, International Harvester (IHC): E545121X, International Harvester (IHC): ZJU545121X, Mack: 2104-545121X, Navistar: 1676146C91, Navistar: 545121X, Navistar: D545121X, Navistar: DS545121X, Navistar: E545121X, Navistar: ETN0039521, Navistar: ZJU545121X, Paccar Parts: 5-4-5121X, UAP: 5-4-5121X, Volvo Cars: 1728875, Volvo Cars: 2104-545121X, Volvo Cars: G15502990, Volvo Cars: SP 545121X, P5-4-5121X, 39521, 039521, 5-4-1641

UPC:

00023913218706

Series:

1610

Material:

Steel

Prop 65:

No

Type:

Splined Hole

Spline Count:

10

Involute Spline:

N

Hub Diameter R:

2.625

Length Thru Hole Q:

2.250

Yoke Style:

BP

C/L To End Hub S:

4.719

C-Bore Depth:

0.250

Assembly:

Y

Includes Slinger/Plug:

Y

Major Diameter:

1.962
