Spicer 5-1-1154 Round Bore Flange

Description

Spicer 5-1-1154 Round Bore Flange

Cross References:
Daimler: SP 5 1 1154HP, Dana Commercial Vehicle Service Parts: 2104-511154, Dana Commercial Vehicle Service Parts: 32MU271, Freightliner Trucks: SP 5 1 1154HP, International Harvester (IHC): 511154, International Harvester (IHC): D511154, International Harvester (IHC): E511154, Mack: 2104-511154, Mack: 32MU271, Navistar: 511154, Navistar: D511154, Navistar: DS511154, Navistar: E511154, Paccar Parts: 5-1-1154, Peterbilt: 511154, UAP: 5-1-1154, Volvo Cars: 2104-511154, Volvo Cars: 32MU271, Volvo Cars: SP 511154, P5-1-1154

UPC:

00023913217907

Series:

1610

Prop 65:

No

Number Of Holes:

8

Flange Type:

Circular

Flange Face To End Of Hub (G):

2.938

Length Thru Hole (F) In.:

2.250

Bolt Hole Circle Diameter In:

6.125

Flange Diameter/Width:

6.875

Flange Hole Diameter:

0.325

Ground Hub Diameter (E) In.:

2.750

Keyway Width In.:

0.438

Major Bore Diameter (D) In.:

1.750

Pilot Diameter In.:

6.625 – FEMALE

SAE Taper:

1.750 SAE TAPER
