Spicer 4-3-1261KX 1550 Sleeve Yoke

Description

Spicer 4-3-1261KX 1550 Sleeve Yoke
431261KX
PLEASE USE THE DANA ONILNE SLIP YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 4 3 1261KX, Daimler: SP 4 3 1261KXHP, Dana Commercial Vehicle Service Parts: 2104-431261KX, Freightliner Trucks: SP 4 3 1261KX, Freightliner Trucks: SP 4 3 1261KXHP, International Harvester (IHC): 431261KX, International Harvester (IHC): D431261KX, International Harvester (IHC): E431261KX, Komatsu: VE7614, Mack: 2104-431261KX, Navistar: 431261KX, Navistar: D431261KX, Navistar: DS431261KX, Navistar: E431261KX, Paccar Parts: 4-3-1261KX, Sandvik: 001022-056, Terex: 12403-2, UAP: 4-3-1261KX, Volvo Cars: 2104-431261KX, Volvo Cars: SP 431261KX, P4-3-1261KX

UPC:

00023913214128

Series:

1550

Material:

Steel

Prop 65:

No

Style:

SR

Joint Angle 1:

8.0

Bearing Cap Diameter (D) In.:

1.375

Outside Yoke Dimension (E) In.:

5.25

C/L To End Of Spline (J) In.:

3.500

C/L To Face Of Plug (F) In.:

1.125

No. Of Splines:

16

Involute:

N

Spline O.D.:

2.500
