Spicer 4-2-689 1550 Flange Yoke

Description

Spicer 4-2-689 1550 Flange Yoke
42689

PLEASE USE THE DANA ONILNE FLANGE YOKE CATALOG TO SELECT YOUR PART NUMBERS

4-2-689
JOINT SERIES:1550
BOLT CIRCLE:6.125
BOLT DIAMETER:.375-D
BOLT HOLE QUANTITY:8
FLANGE FACE TO JOINT CENTERLINE:2.000
FIGURE:2
FLANGE PILOT:6.625M
NOTES:Flange has pilot for brake

Cross References:
AGCO: AG604474, Blue Bird: 155NF10, Broderson: 33330019, Broderson: 333-30019, Caterpillar: 471-4102, Caterpillar: 471-6192, Daimler: SP 4 2 689, Daimler: SP 4 2 689HP, Dana Commercial Vehicle Service Parts: 2104-42689, Dresser: 57137259, Emergency One: 360187, Euclid: E4059971, Freightliner Trucks: SP 4 2 689, Freightliner Trucks: SP 4 2 689HP, Ingersoll/Rand: 57137259, International Harvester (IHC): 42689, International Harvester (IHC): D42689, International Harvester (IHC): D4-2-689, International Harvester (IHC): E42689, Komatsu: VE3436, Mack: 2104-42689, Meritor: 155NF10, Navistar: 42689, Navistar: D42689, Navistar: D4-2-689, Navistar: DS42689, Navistar: E42689, Ottawa Truck: 90022899, Paccar Parts: 4-2-689, Peterbilt: 4 2 689, Terex: 1453205, Terex: 702575, UAP: 4-2-689, VME: E4059971, Volvo Cars: 2104-42689, Volvo Cars: E4059971, Volvo Cars: SP 42689, P4-2-689

UPC:

00023913212827

Series:

1550

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Reproductive Harm — www.p65warnings.ca.gov

Number Of Bolt Holes:

8

Bolt Circle Dia. In. (B):

6.125

Bolt Hole Dia. In (B):

.375 – DRILLED

Flange Face To C/L In. (G):

2.000

Flange Or Swing Dia. In. (A):

6.875

Pilot Dia. M: Male F: Female (C):

6.625 – MALE

Joint Angle 1:

22

Design:

Circular

Outside Yoke Dimension In.(E):

5.25

Yoke Bearing Dimension In. (D):

1.375
