Spicer 3-53-1811 Splined Stub Shaft

Description

Spicer 3-53-1811 Splined Stub Shaft
3531811
PLEASE USE THE DANA ONILNE SLIP YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 3 53 1811, Daimler: SP 3 53 1811HP, Dana Commercial Vehicle Service Parts: 3-53-221, Freightliner Trucks: SP 3 53 1811, Freightliner Trucks: SP 3 53 1811HP, International Harvester (IHC): 3531811, International Harvester (IHC): D3531811, International Harvester (IHC): E3531811, Midwest: 3-53-1811R, Navistar: 3531811, Navistar: D3531811, Navistar: DS3531811, Navistar: E3531811, Paccar Parts: 3-53-1811, UAP: 3-53-1811, Volvo Cars: SP 3531811, P3-53-1811

UPC:

00023913231712

Thread Size:

1.000-20 in

Series:

1310-1410

Material:

Steel

Prop 65:

No

Style:

2

Involute:

N

Spline O.D.:

1.500

Fits Tube Diameter:

3.000

Butt Diameter:

2.845

Fits Tube Wall:

.083

Bearing Diameter (C) In.:

1.574

Bearing Diameter (Max):

1.5748

Spline End To Weld (K) In.:

4.000

Spline Length (L) In.:

1.844

Bearing Diameter (Min):

1.5743

For Use With:

End Yoke Or Companion Flange

Shoulder Diameter (B) In.:

1.938

Spline End To Brg Shoulder (Y):

2.938

Shoulder Length (G) In.:

.812
