Spicer 3-4-283-1 End Yoke

Description

Spicer 3-4-283-1 End Yoke

Cross References:
Cameco: 0270006411, Cameco: 25301, Daimler: SP 3 4 283 1, Daimler: SP 3 4 283 1HP, Dana Commercial Vehicle Service Parts: 2104-34283, Dana Commercial Vehicle Service Parts: 3-4-283, Elgin: 42658-30, Freightliner Trucks: SP 3 4 283 1, Freightliner Trucks: SP 3 4 283 1HP, Heyco: 837225, International Harvester (IHC): 342831, International Harvester (IHC): D34283, International Harvester (IHC): D342831, International Harvester (IHC): E342831, Mack: 2104-34283, Mack: 2104-342831, McNeilus: 1426474, Navistar: 342831, Navistar: D34283, Navistar: D342831, Navistar: DS342831, Navistar: E34283, Navistar: E342831, Neapco: N3-4-283-1, Paccar Parts: 3-4-283-1, Peterbilt: 1426474, Peterbilt: 2AT142, Peterbilt: 4192099, Volvo Cars: 2104-34283, Volvo Cars: 3 4 283, Volvo Cars: 3919547, Volvo Cars: SP 342831, P3-4-283-1, 34283

UPC:

00023913228989

Series:

1350

Material:

Steel

Prop 65:

No

Type:

Straight Round Hole

Involute Spline:

N

Hub Diameter R:

2.250

Length Thru Hole Q:

1.500

Yoke Style:

BS

C/L To End Hub S:

3.000

Joint Angle 1:

22

Yoke Bearing Dimension (In) D:

1.188

Keyway Location W:

12

Set Screw Location W:

6

Set Screw Hole Diameter (In):

0.375

Outside Yoke Dimension (In) E:

3.625

Hole Diameter (In) P:

1.250

Sae Keyway Width (In) X:

0.314

Hole Diameter – Max:

1.2505

Hole Diameter – Min:

1.2495

Keyway Width – Max:

0.3155

Keyway Width – Min:

0.3135
