Spicer 3-4-1111-1 End Yoke

Description

Spicer 3-4-1111-1 End Yoke
3411111
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 3 4 1111 1HP, Dana Commercial Vehicle Service Parts: 2104-341111, Dana Commercial Vehicle Service Parts: 3-4-1111, Freightliner Trucks: SP 3 4 1111 1HP, International Harvester (IHC): 3411111, International Harvester (IHC): D3411111, International Harvester (IHC): E341111, International Harvester (IHC): E3411111, Mack: 2104-341111, Navistar: 3411111, Navistar: D3411111, Navistar: DS3411111, Navistar: E341111, Navistar: E3411111, Peterbilt: 1411776, Volvo Cars: 2104-341111, Volvo Cars: 3-4-1111, Volvo Cars: SP 3411111, 341111, P3-4-1111-1

UPC:

00023913236281

Series:

1350

Material:

Steel

Prop 65:

No

Type:

Splined Hole

Spline Count:

10

Involute Spline:

N

Hub Diameter R:

1.750

Length Thru Hole Q:

1.812

Yoke Style:

BS

C/L To End Hub S:

3.312

Yoke Bearing Dimension (In) D:

1.188

Major Diameter:

1.375

Outside Yoke Dimension (In) E:

3.625
