Spicer 3-3-1621KX 1480 Sleeve Yoke

Description

Spicer 3-3-1621KX 1480 Sleeve Yoke
331621KX
PLEASE USE THE DANA ONILNE SLIP YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 3 3 1621KX, Daimler: SP 3 3 1621KXHP, Dana Commercial Vehicle Service Parts: 2104-331621KX, Franklin Equipment: 021337, Freightliner Trucks: SP 3 3 1621KX, Freightliner Trucks: SP 3 3 1621KXHP, International Harvester (IHC): 3 3 1621KX, International Harvester (IHC): 331621KX, International Harvester (IHC): D331621KX, International Harvester (IHC): E331621KX, Mack: 2104-331621KX, Navistar: 3 3 1621KX, Navistar: 331621KX, Navistar: D331621KX, Navistar: DS331621KX, Navistar: E331621KX, Paccar Parts: 3-3-1621KX, UAP: 3-3-1621KX, Volvo Cars: 2104-331621KX, Volvo Cars: SP 331621KX, P3-3-1621KX

UPC:

00023913215859

Series:

1480

Material:

Steel

Prop 65:

No

Style:

SR

Joint Angle 1:

8.0

Bearing Cap Diameter (D) In.:

1.375

Outside Yoke Dimension (E) In.:

4.438

C/L To End Of Spline (J) In.:

3.719

C/L To Face Of Plug (F) In.:

1.188

No. Of Splines:

10

Involute:

N

Spline O.D.:

2.250
