Spicer 3-3-1511KX 1410 Series Slip Yoke

Description

Spicer 3-3-1511KX 1410 Series Slip Yoke
331511KX
PLEASE USE THE DANA ONILNE SLIP YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 3 3 1511KX, Daimler: SP 3 3 1511KXHP, Dana Commercial Vehicle Service Parts: 2104-331511KX, Freightliner Trucks: SP 3 3 1511KX, Freightliner Trucks: SP 3 3 1511KXHP, International Harvester (IHC): 331511KX, International Harvester (IHC): D331511KX, International Harvester (IHC): E331511KX, Mack: 2104-331511KX, Navistar: 331511KX, Navistar: D331511KX, Navistar: DS331511KX, Navistar: E331511KX, Paccar Parts: 3-3-1511KX, Peterbilt: 1464211, Terex: 992132, UAP: 3-3-1511KX, Volvo Cars: 2104-331511KX, Volvo Cars: SP 331511KX, P3-3-1511KX

UPC:

00023913230715

Series:

1410

Material:

Steel

Prop 65:

No

Style:

SR

Joint Angle 1:

0.0

Bearing Cap Diameter (D) In.:

1.188

Outside Yoke Dimension (E) In.:

4.438

C/L To End Of Spline (J) In.:

3.250

C/L To Face Of Plug (F) In.:

1.188

No. Of Splines:

16

Involute:

N

Spline O.D.:

1.750
