Spicer 3-28-1327X Ball Stud CV Yoke 1350

Description

Spicer 3-28-1327X Ball Stud CV Yoke 1350
3281327X
PLEASE USE THE DANA ONILNE WELD YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 3 28 1327XHP, Freightliner Trucks: SP 3 28 1327XHP, International Harvester (IHC): 3281327X, International Harvester (IHC): D3281327X, International Harvester (IHC): E3281327X, Meritor: 135N281327X, Navistar: 3281327X, Navistar: D3281327X, Navistar: DS3281327X, Navistar: E3281327X, Paccar Parts: 3-28-1327X, UAP: 3-28-1327X, Volvo Cars: SP 3281327X, P3-28-1327X

UPC:

00023913230883

Series:

1350

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Outside Yoke Dimension (In) E:

3.785

Fits Tube Diameter (In):

3.00

Angle 1:

13

Ball Stud Diameter (In) H:

0.500

Ball Stud Length (In) L:

0.590

Butt Diameter (In) F:

2.844

C/L To Ball Stud End (In) J:

1.732

Fits Tube Wall (In):

0.083

Mfg Process:

Welded

Bearing Cap Diameter (In) D:

1.188

Slinger Or Seal Part Number:

2-86-418

C/L To Weld (In) K:

1.440
