Spicer 3-1-3431 Drive Shaft Companion Flange

Description

Drive Shaft Companion Flange

Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non genuine parts simply cannot deliver.
Applications: CHELSEA – 4600, 4605, 4608, 900, 901

Cross References:
Daimler: SP 3 1 3431, Daimler: SP 3 1 3431HP, Freightliner Trucks: SP 3 1 3431HP, International Harvester (IHC): D313431, International Harvester (IHC): E313431, Navistar: 3-1-3431, Navistar: D313431, Navistar: DS313431, Navistar: E313431, Sandvik: 3000139, Volvo Cars: SP 313431, 313431, P3-1-3431

UPC:

00023913230111

Series:

1350

Material:

Steel

Prop 65:

No

Spline Count:

10

Involute Spline:

N

Companion Flange Assembly:

N

Flange Face To End Of Hub (G):

2.906

Ground Hub Diameter In.:

2.000

Length Thru Hole (F) In.:

2.188

Major Diameter (D) In.:

1.500

Pilot Diameter (C) In.:

2.750 – FEMALE

Bolt Circle Dia.(B) In.(FL YK):

3.750

Bolt Hole Diameter In (FL YK):

0.438 – DRILLED

Number Of Holes (FL YK):

4

Brake Drum Pilot Diameter In.:

3.112
