Spicer 202990-1 DRIVE SHAFT

Description

Drive Shaft

Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

Cross References:
Caterpillar: 28Y25, Caterpillar: 8C2252, Caterpillar: 8C-2252, Cusco Fab: DR017340, Daimler: SP 202990 1, Dana Commercial Vehicle Service Parts: 2104-2029901, Dresser: 82144809, Freightliner Trucks: SP 202990 1, Ingersoll/Rand: 82144809, International Harvester (IHC): 2029901, International Harvester (IHC): E2029901, Mack: 2104-2029901, Navistar: 2029901, Navistar: DS2029901, Navistar: E2029901, UAP: 202990-1, Volvo Cars: 2104-2029901, Volvo Cars: SP 2029901

UPC:

00023913245689

Series:

1480

Prop 65:

Yes

Phased – Degrees:

0.0000

Unwelded/Welded Assembly:

Welded

Shaft Material:

Steel

Max Slip (IN):

1.0000

Max Slip (MM):

25.4000

Notes:

Driveshaft

Mid Slip (MM):

12.7000

Mid Slip (IN):

0.5000

FF(Flange Face) To FF (MM)-COLL:

215.9000

CV Joints Included:

No

Slip Assembly:

No

FF(Flange Face) To FF (IN)-COLL:

8.5000

Phased (Yes/No):

No

FF(Flange Face) To FF (IN)-INST:

9.0000

FF(Flange Face) To FF (MM)-INST:

228.6000

1/2 Max Slip (IN):

0.5000

1/2 Max Slip (MM):

12.7000

California Proposition 65:

WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov

CL Yoke To CL Yoke (IN) – COLL:

5.5000

CL Yoke To CL Yoke (MM) – COLL:

139.7000

End 1 Type SJ Side:

3-2-489

CL Yoke To Flange Face (MM)-COLL:

177.8000

CL Yoke To Flange Face (MM)-INST:

190.5000

CL Yoke To Flange Fac e(IN)-COLL:

7.0000

End 2 TJ Side:

3-2-489
