Spicer 2-82-21 Yoke Shaft

Description

Spicer 2-82-21 Yoke Shaft
28221
PLEASE USE THE DANA ONILNE CENTER YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 2 82 21, Daimler: SP 2 82 21HP, Dana Commercial Vehicle Service Parts: 2104-28221, Freightliner Trucks: SP 2 82 21, Freightliner Trucks: SP 2 82 21HP, International Harvester (IHC): 28221, International Harvester (IHC): D28221, International Harvester (IHC): E28221, Mack: 2104-28221, Motor Coach Industries: G5005800, Navistar: 28221, Navistar: D28221, Navistar: DS28221, Navistar: E28221, Paccar Parts: 2-82-21, Peterbilt: 2-FP-671, Prevost: G5005800, UAP: 2-82-21, Volvo Cars: 2104-28221, Volvo Cars: SP 28221, P2-82-21

UPC:

00023913230098

Series:

1310

Prop 65:

No

Style:

SR

Spline Count:

16

Centerline To End Of Splne (K):

5.312

Major Spline Diameter:

1.375

Spline Length (L) In:

2.250

Spline Hole Minor Diameter:

1.172

Spline Width:

0.125

End/Spline To Point/Rad. (R):

3.844

Involute Spline:

N

Bearing Cap Diameter (D) In.:

1.062

Outside Yoke Dimension (E) In.:

3.469

Angle 1:

16.0
