Spicer 2-53-691 Stub

Description

Spicer 2-53-691 Stub
253691
PLEASE USE THE DANA ONILNE SLIP YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 2 53 691, Daimler: SP 2 53 691HP, Freightliner Trucks: SP 2 53 691, Freightliner Trucks: SP 2 53 691HP, International Harvester (IHC): 1662833C1, International Harvester (IHC): 253691, International Harvester (IHC): D253691, International Harvester (IHC): E253691, Meritor: 121N53691, Navistar: 1662833C1, Navistar: 253691, Navistar: D253691, Navistar: DS253691, Navistar: E253691, Neapco: N2-53-691, Paccar Parts: 2-53-691, UAP: 2-53-691, Volvo Cars: SP 253691, P2-53-691

UPC:

00023913236694

Series:

1210-1350

Material:

Steel

Prop 65:

No

Style:

2

Involute:

N

Spline O.D.:

1.3750

Fits Tube Diameter:

3

Butt Diameter:

2.881

Fits Tube Wall:

0.065

Bearing Diameter (C) In.:

1.378

Bearing Diameter (Max):

1.3784

Spline End To Weld (K) In.:

8.875

Spline Length (L) In.:

2.500

Bearing Diameter (Min):

1.3779

For Use With:

Outboard Slip Yoke

Shoulder Diameter (B) In.:

1.688

Spline End To Brg Shoulder (Y):

7.812

Bearing Diameter Length:

1.54

Bearing Diameter Radius:

0.19

Shoulder Length (G) In.:

0.812
