Spicer 2-40-1221 Splined Stub Shaft

Description

Spicer 2-40-1221 Splined Stub Shaft
2401221
PLEASE USE THE DANA ONILNE SLIP YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 2 40 1221, Daimler: SP 2 40 1221HP, Freightliner Trucks: SP 2 40 1221, Freightliner Trucks: SP 2 40 1221HP, International Harvester (IHC): 2401221, International Harvester (IHC): D2401221, International Harvester (IHC): E2401221, Meritor: 131N401221, Navistar: 2401221, Navistar: D2401221, Navistar: DS2401221, Navistar: E2401221, Neapco: N2-40-1221, Peterbilt: 1453107, Rockwell International: 131N-40-1221, UAP: 2-40-1221, Volvo Cars: SHP2401221, Volvo Cars: SP 2401221, N2-40-1221-1, N2-40-1221-1X, P2-40-1221, N24012211

UPC:

00023913233686

Series:

1310-1350

Material:

Steel

Prop 65:

No

Spline Count:

16

Involute Spline:

N

Major Diameter:

1.375

Fits Tube Diameter:

3.000

Butt Diameter:

2.881

End Of Spline To Radius (R):

5.625

End Of Spline To Weld (K):

6.438

Fit Tube Wall Thickness:

.065

Length Of Spline (L):

2.250

Glidecote Spline:

Y
