Spicer 2-4-613 End Yoke

Description

Spicer 2-4-613 End Yoke

Cross References:
Daimler: SP 2 4 613, Daimler: SP 2 4 613HP, Dana Commercial Vehicle Service Parts: 2104-24613, Freightliner Trucks: SP 2 4 613, Freightliner Trucks: SP 2 4 613HP, International Harvester (IHC): 2 4 613, International Harvester (IHC): 24613, International Harvester (IHC): D24613, International Harvester (IHC): E24613, Mack: 2104-24613, Navistar: 2 4 613, Navistar: 24613, Navistar: D24613, Navistar: DS24613, Navistar: E24613, Paccar Parts: 2-4-613, UAP: 2-4-613, Volvo Cars: 2104-24613, Volvo Cars: 27153-5012, Volvo Cars: SP 24613, Volvo Cars: SP2-4-613, P2-4-613

UPC:

00023913232542

Series:

1310

Material:

Steel

Prop 65:

No

Type:

Straight Round Hole

Involute Spline:

N

Hub Diameter R:

2.125

Yoke Style:

SR

C/L To End Hub S:

2.561

Joint Angle 1:

17

Yoke Bearing Dimension (In) D:

1.062

Keyway Location W:

12

Set Screw Hole Diameter (In):

0.375

Outside Yoke Dimension (In) E:

3.469

Hole Diameter (In) P:

1.250

Sae Keyway Width (In) X:

0.312

Hole Diameter – Max:

1.2505

Hole Diameter – Min:

1.2495

Keyway Width – Max:

0.3125

Keyway Width – Min:

0.3115
