Spicer 2-4-523 1310 Round Bore 1.125

Description

Spicer 2-4-523 1310 Round Bore 1.125

Cross References:
Daimler: SP 2 4 523, Daimler: SP 2 4 523HP, Dana Commercial Vehicle Service Parts: 2104-24523, Emergency One: 566157, Freightliner Trucks: SP 2 4 523, Freightliner Trucks: SP 2 4 523HP, International Harvester (IHC): 24523, International Harvester (IHC): D24523, International Harvester (IHC): E24523, Mack: 2104-24523, Navistar: 24523, Navistar: D24523, Navistar: DS24523, Navistar: E24523, Paccar Parts: 2-4-523, Paccar Parts: EM939877, Paccar Parts: SP 2-4-523, UAP: 2-4-523, Volvo Cars: 2104-24523, Volvo Cars: SP 24523, P2-4-523

UPC:

00023913231842

Series:

1310

Material:

Steel

Prop 65:

No

Type:

Straight Round Hole

Involute Spline:

N

Hub Diameter R:

2.125

Yoke Style:

SR

C/L To End Hub S:

2.562

Joint Angle 1:

17

Yoke Bearing Dimension (In) D:

1.062

Keyway Location W:

12

Set Screw Location W:

6

Set Screw Hole Diameter (In):

0.375

Outside Yoke Dimension (In) E:

3.469

Hole Diameter (In) P:

1.125

Sae Keyway Width (In) X:

0.312

Hole Diameter – Max:

1.1255

Hole Diameter – Min:

1.1245

Keyway Width – Max:

0.3155

Keyway Width – Min:

0.3135
