Spicer 2-3-12051X 1330 Transmission Sleeve Yoke

Description

Spicer 2-3-12051X 1330 Transmission Sleeve Yoke
2312051X
PLEASE USE THE DANA ONILNE SLIP YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Allison Transmission: 12472412, Allison Transmission: 12542963, Allison Transmission: 15580368, Daimler: SP 2 3 12051X, Daimler: SP 2 3 12051XHP, Dana Commercial Vehicle Service Parts: 2104-2312051X, Dana Commercial Vehicle Service Parts: 2-3-12051XSB, Dana Commercial Vehicle Service Parts: 2-3-9921X, Freightliner Trucks: SP 2 3 12051X, Freightliner Trucks: SP 2 3 12051XHP, General Motors: 12472412, General Motors: 12542963, General Motors: 15580368, International Harvester (IHC): 2312051X, International Harvester (IHC): D2312051X, International Harvester (IHC): E2312051X, International Harvester (IHC): SB2312051X, International Harvester (IHC): SD2312051X, Mack: 2104-2312051X, McNeilus: 1486928, Navistar: 2312051X, Navistar: D2312051X, Navistar: DS2312051X, Navistar: E2310931X, Navistar: E2312051X, Navistar: E239921X, Navistar: SB2312051X, UAP: 2-3-12051X, Volvo Cars: 2104-2312051X, Volvo Cars: SP 2312051X, P2-3-12051X, 74088635, N3R-3-12051KX, 7848635, N3R312051X, N3R-3-12051X, 40036409, 3R03-700

UPC:

00023913229696

Series:

1330

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Style:

SR

Bearing Cap Diameter (D) In.:

1.062

Outside Yoke Dimension (E) In.:

3.875

No. Of Splines:

26/27 I

Involute:

Y

Spline O.D. (STD):

1.176

To End Of Spline (J) In.:

6.760

Counter Bore Depth:

.410

Counter Bore Diameter:

1.217

Hub Diameter (R) In.:

1.502
