Spicer 170-4-261-1X Spl End Yoke

Description

Spicer 170-4-261-1X Spl End Yoke
17042611X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

Cross References:
Daimler: SP 170 4 261 1X, Daimler: SP 170 4 261 1XHP, Dana Commercial Vehicle Service Parts: 210839, Eaton: 170 4 261 1X, Freightliner Trucks: 30071-3406, Freightliner Trucks: SP 170 4 261 1X, Freightliner Trucks: SP 170 4 261 1XHP, International Harvester (IHC): 17042611X, International Harvester (IHC): 2502776C91, International Harvester (IHC): D17042611X, International Harvester (IHC): E17042611X, McNeilus: 1358466, Midwest: 170-4-261-1XR, Navistar: 17042611X, Navistar: 2502776C91, Navistar: D17042611X, Navistar: DS17042611X, Navistar: E17042611X, Navistar: ETN0210839, Neapco: N170-4-261-1X, Paccar Parts: 170-4-261-1X, Peterbilt: 1358466, UAP: 170-4-261-1X, Volvo Cars: 3099411, Volvo Cars: SP 17042611X, P170-4-261-1X

UPC:

00023913248598

Series:

SPL170

Material:

Steel

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Type:

Splined Hole

Spline Count:

39

Involute Spline:

Y

Hub Diameter R:

3.000

Length Thru Hole Q:

2.281

Yoke Style:

HR

C/L To End Hub S:

5.156

C-Bore Depth:

0.250

Assembly:

Y

Includes Slinger/Plug:

Y

Yoke Bearing Dimension (In) D:

2.166

Major Diameter:

2.024

Outside Yoke Dimension (In) E:

6.456
