Spicer 1202TB104-8 Steer Axle Beam

Description

Suspension I-Beam Axle

Do not risk your vehicles performance on knock-off axle components. Dana offers the genuine Spicer medium- and heavy-duty axle components you need, along with the peace of mind that comes from knowing your axle contains only brand new genuine Spicer parts.

Cross References:
Daimler: ETN1202TB1048, Dana Commercial Vehicle Service Parts: 1202TB104-2, International Harvester (IHC): H1202TB1042, International Harvester (IHC): H1202TB1048, Mack: 2719-1202TB1048, Navistar: DS1202TB1048, Navistar: H1202TB1042, Navistar: H1202TB1048, Paccar Parts: 1202TB104-8, Paccar Parts: 1202TB104-8ETN, Volvo Cars: SP 1202TB1048, 1202TB1048

UPC:

00023913201098

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Type:

I-Beam

Ctr Drill Dia And Depth (IN):

.812 x .780

Ctr Drill Dia And Depth (MM):

20.625 x 19.812

Ctr Hole To Ctr Out Patrn (IN):

2.406

Ctr Hole To Ctr Out Patrn (MM):

61.11

Drill Pattern Length (IN):

4.250

Drill Pattern Length (MM):

107.95

Drill Pattern Width (IN):

4.812

Drill Pattern Width (MM):

122.23

Otr Drill Patrn And Dia (IN):

4 x .812

Otr Drill Patrn And Dia (MM):

4 x 20.625

Spring Mount Ctr To Ctr (IN):

34.00

Spring Mount Ctr To Ctr (MM):

863.6
