45531 Spicer Dana 60 Disconnect Dodge Output Intermediate Axle Shaft

Description

45531 Spicer Dana 60 Disconnect Dodge Output Intermediate Axle Shaft
4746814
Please use the Dana General Axle Information Catalog to help select your part numbers
Please use the Dana Jeep Light Axle parts catalog to help select your part numbers
Please use the Dana Ford Light Axle parts catalog to help select your part numbers
Please use the Dana Nissan light axle parts catalog to help select your part numbers
Please use the Dana Chrsyler Light Axle parts catalog to help select your part numbers
Please use the Dana 1978 to 1998 all models light axle parts catalog to help select your part numbers
Please use the Dana 1967 to 1978 all models light axle parts catalog to help select your part numbers
Please use the Dana 1979 to 1984 Miscellaneous models light axle parts catalog to help select your part numbers
Please use the Dana 1979 to 2002 GM light axle parts catalog to help select your part numbers

Cross References:
Chrysler: 4746814, Navistar: DS45531, Yukon Gear: YAD45531, P45531

UPC:

00023913134464

Application:

DANA 60

Length (IN):

20.520

Material:

Steel

Prop 65:

No

Axle Model:

DANA 60

Quantity:

1

Includes Tone:

N

Spline Count:

30 Inboard / 15 Outboard

Cover Bolt Quantity:

10

Axle Type:

Complete Assembly

ABS/Non-ABS:

Non-ABS

ABS Sensor Ring Included:

No

ABS Sensor Ring Installed:

N

Axle Shaft Included:

Y

Bearing Included:

N

Full-Floating Or Semi-Floating:

Semi-Floating

Inner Axle Included:

Y

Outer Axle Included:

Y

Retainer Ring Included:

N

Seal Included:

N

Seal Kit Included:

N

U-Joint Included:

N

Wheel Bearing Included:

N

Wheel Bolt Prep Kit Included:

N

Wheel Nuts Included:

N

Wheel Studs Included:

N

Location:

Front Inner

Number Of Teeth B:

15

Spline Diameter B:

1.590

Spline Length (In) C:

0.930

Length (Mm):

521.208

End Spln – End Spln Lngth A:

19.770

Number Of Teeth D:

30

Spline Diameter D:

1.310

Spline Length (In) E:

2.000
