2006106-5 Dana M205 Front 3.36 Ring & Pinion Gear Set for Nissan Titan

Description

2006106-5 Dana M205 Front 3.36 Ring & Pinion Gear Set for Nissan Titan
Fits 2004-2015
Please use the Dana General Axle Information Catalog to help select your part numbers
Please use the Dana Jeep Light Axle parts catalog to help select your part numbers
Please use the Dana Ford Light Axle parts catalog to help select your part numbers
Please use the Dana Nissan light axle parts catalog to help select your part numbers
Please use the Dana Chrsyler Light Axle parts catalog to help select your part numbers
Please use the Dana 1978 to 1998 all models light axle parts catalog to help select your part numbers
Please use the Dana 1967 to 1978 all models light axle parts catalog to help select your part numbers
Please use the Dana 1979 to 1984 Miscellaneous models light axle parts catalog to help select your part numbers
Please use the Dana 1979 to 2002 GM light axle parts catalog to help select your part numbers

Cross References:
Navistar: DS20061065, Nissin: 38100 8S11B, Nissin: 381008S11B, P2006106-5, 20061065

UPC:

00023913127855

Application:

M226

Pinion Shaft Diameter:

1.627 in

Ring Gear Bolt Thread In.:

.437-20 in

Ring Gear Diameter (In.):

8.070 in

Prop 65:

Yes

California Proposition 65:

WARNING: Cancer – www.p65warnings.ca.gov

Axle Model:

M205

New Or Remanufactured:

New

Gear Ratio:

3.36

Ring Teeth Count:

47

Carrier Breaks:

2.44 To 4.10

Cover Bolt Quantity:

9

Include Installation Kit:

Y

On Vehicle Location:

Front

Pinion Gear Tooth Quantity:

14

Pinion Spline Count:

24

Ring Gear Bolt Qty:

10

Ring Gear Rotation:

Reverse

Axle Type:

Semi Floating

Pinion Gear Included:

Y

Ring Gear Included:

Y

Pinion Nut Included:

Y
